6YL-130 vegetable oil extraction
1,Model: 6YL-130
2,Capacity: 400-500kg/h
3,Power： 15kw
4,Shining point: suitable for almost different oil seeds.could use cold press and can use hot press and add one roaster.
5,Delivery time and package: 7-10 days fumicated wood box international standard
Skype ID: shining0603
Working operation Principle of vegetable oil extraction/oil extract/oil expeller
When oil press operating prepared material enters chamber from the hopper and then moves forwards by the rotating pressing screw and is
pressed.Under the high-pressure condition in the chamber, friction between material and screw, between material and chamber will be created which also creates friction and relative movement among material particles. On the other hand toot diameter of the pressing screw caries larger
from one end to the other, hence, rotating, it not only prshes particles moving forwards but turns them outwards as well, meanwhile, particle
adjacent the screw will rotation along with screw`s rotating, causing every particle inside the chamber to possess different speed therefore
relative movement among particle creates heat which is necessary during manufacturing because of helping protein change property, damage
colloid, increase plasticity, decrease oil`elasticity, resulting in high oil productivity.
vegetable oil extraction different model data
| NAME | TYPE | N.WEIGHT (KG) |
POWER (KW) |
PACKING DIMENDION (mm) |
CAPACITY kg/h |
| 6YL-single oil press |
68 | 165 | 5.5 | 930*490*820 | 30-50 |
| 80 | 420 | 5.5 | 1860*500*670 | 100-150 | |
| 95 | 680 | 7.5 | 2130x610x790 | 200 | |
| 100 | 700 | 7.5 | 1700 x 670 x 1320 | 250 | |
| 120 | 800 | 11 | 2080*670*775 | 250-300 | |
| 130 | 850 | 15 | 2300x800x790 | 400-500 | |
|
160 |
1000 | 18 22 |
2450x950x1400 | 800-1000 |
vegetable oil extraction oil output
| Oil seeds | Oil content(%) | Oil cake thickness(mm) | cake residual oil rate(%) |
| Sesame seeds | 43-45 | 1.0-1.5 | ≤7 |
| peanuts | 42-44 | 0.8-2 | ≤8 |
| Rape seeds | 28-43 | 1.0-1.5 | ≤8 |
| Sunflower seeds | 42-45 | 1.2-1.5 | ≤8 |
| Soybean seeds | 15-17 | 0.8-1.5 | ≤7 |
